Mini Grabber Test Clip with Banana Jack
|
Features:
- This Minigrabber test clip has a standard banana jack built right into the plunger.
- Excellent for attaching the Grabber test clip directly to the end of a banana plug patch cord.
|
|
Materials:
Contact: Beryllium Copper per QQ-C-533, Alloy 165, ¼ HM.
Spring: Stainless steel #302
Banana Jack: Brass per QQ-B-626, Alloy 360, ½ Hard.
Finish:
Contact: Gold plated per MIL-G-45204, Type I, Class 00
Banana Jack: Nickel plated per QQ-N-290, Class 1, 200/300 microinches.
Insulation: Glass filled Nylon.
Marking: “POMONA ELECTRONICS, CALIF.” “4723” “MINIGRABBER”.
Ratings:
Operating Temperature: +102°C. (+216°F.) Max.
Operating Voltage: Hand-held testing: 30VAC/60VDC Max.
Current: 5 Amperes | |
|
 |
|
|
|
| |
|
|
|
