Pomona 3220 Miniature alligator clip to stacking banana plug patch cord
|
Features:
- Provides cross hole for cross stacking, and a jack for vertical stacking.
- Allows an Alligator Clip with leads to be used from a Banana Jack.
|
|
Materials:
Conn: Insulated Minigator Clip
Material: Steel.
Finish: Nickel plated.
Insulator: Vinyl.
Color: Matches color of wire.
Conn: Banana Plug
Material: Spring, Beryllium Copper per QQ-C-533, Alloy 172, Cond. HT. Plug Body, Brass per QQ-B-626, Alloy 360, ½ Hard.
Finish: Nickel plated per QQ-N-290, Class 2, 200/300 microinches.
Insulation: Polypropylene molded to plug body and wire. Color: Matches color of wire.
Marking: “POMONA 3220-XX”
Ratings:
Operating Temperature: +50º C. (+122º F.) Max.
Operating Voltage:
Hand-held testing: 30VAC/60VDC Max.
Current: 5 Amperes | |
