[19316]POMONA B/Post to Plug ( 2894 ) / Binding Post to Banana Plug |
|
|
|
|
100000ÀÌ»ó ±¸¸Å½Ã ¹«·á¹è¼Û
³³Ç°/³³±â °ßÀû¿äûÀº ÀüÈÁֽñ⠹ٶø´Ï´Ù. |
|
|
|
|
![](images/line.gif) |
![](images/st_05.gif) |
|
![](images/line.gif) |
![](images/st_20.gif) |
Binding Post to Banana Plug
Features:
- Features insulated binding post for rapid mounting and interchangeability of components.
- Center cross hole 4.2 (.166) dia. Provides side stackup connection.
|
Materials:
Upper Conn.: Binding Post – Insulated Material: Binding Post Body – Brass per QQ-B-626, Alloy 360, ¨ö Hard. Finish: Nickel plated per QQ-N-290, Class 2, 200/300 micro-inches. Insulation: Polycarbonate. Color: See Ordering Information. Insulation: ABS molded to binding post and banana plug body. Color: Black. Marking: ¡°2894 POMONA ELECTRONICS CALIF.¡± Lower Conn.: Banana Plug Material: Spring – Beryllium Copper per QQ-C-533, Alloy 172, Cond. Plug Body – Brass per QQ-B-626, Alloy 360, ¨ö Hard Finish: Nickel plated per QQ-N-290, Class 2, 200/300 micro-inches.
Ratings:
Operating Temperature: +50¡ÆC. (+122¡ÆF.) Max. Operating Voltage: 2500 VDC Current: 15 Amperes | |
